This Download Contains the BLÜCHER® full range of Hub Drains

Hub drains with round top 160 and 250 mm / 6 and 10”

Vertical outlet 75 and 110 mm / 2, 3, 6, and 8”
The product is made from 1.25 mm acid-pickled stainless steel.
Designed in accordance with EN1253.

Key Component Features:

User selectable Hub Drain
User selectable waste basket
Automated product codes
Pre-selected concrete cut out / base concrete slab option for installation purpose

Products: HUB-102, HUB-103, HUB-104, HUB-106, HUB-108

Search Opt.: blucher / HUB

_AuthorIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeD2030300
Asset TypeFixed
BHD2_3_4Yes
BHD6_8No
BIM Object NameBlucher_PlumbingFixture_HubDrains
Classification NameUniclass2015
Classification ValuePr_65_52_24_24
Code Performancen/a
ColorStainless Steel
Connector Offset25 mm
Constituentsn/a
Created Bymail@blucher.com
Created On2020-11-03T09:00:00
CW ConnectionNo
D160 mm
D1110 mm
Default Elevation0 mm
DescriptionHub drains with round top 160 and 250 mm / 6 and 10”
Documentation Certificateswww.bimstore.co/products/hub-drains/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/hub-drains/document/installation-guide
Documentation Installation Videowww.blucher.com/technical/installation-video-industrial-drains-for-concrete-tiled-floors/
Documentation Literaturewww.bimstore.co/products/hub-drains/document/product-literature
Documentation Maintenancewww.bimstore.co/products/hub-drains/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/hub-drains/document/technical-data-sheet
Drain Product CodeBHD 102
Duration UnitYears
Expected Life50
F160 mm
F1160 mm
Featuresn/a
Filter Basket_780.002.000.05FB : 780.002.000.05
Filter Basket_780.004.020.05FB : 780.004.020.05
Filter Basket Product Code780.002.000.05
Filter Basket TypeFB : 780.002.000.05
Finish2B - Pickled
GradeAISI 304/EN 1.4301 or AISI 316L/EN 1.4404
H177 mm
Has SocketYes
Height From Level0 mm
HW ConnectionNo
Ifc Export AsIfcFlowTerminal
Ifc Export TypeIfcWasteTerminalTypeEnum.FLOORWASTE
KeynoteR10
Lower Part Angle45.00 °
ManufacturerBLÜCHER
Manufacturer NameBLÜCHER
MaterialAvailable in Stainless Steel AISI 304 & Stainless Steel AISI 316L
ModelBLÜCHER Hub Drains
Model NumberBHD 102
Model ReferenceBLÜCHER Hub Drains
NBS DescriptionDrainage channels with gratings
NBS Object NameBLÜCHER - Drainage channels with gratings
NBS Office Master Tagn/a
NBS Reference90-05-20/422
Nominal Depth160 mm
Nominal Length160 mm
Production Year2020
Referenced StandardEN1253
Replacement Costn/a
ShapeRound
Size160mm(W) x 160mm(L) x 281mm(H) x 50mm(Dia)
Socket D150 mm
Socket Length99 mm
Socket TypeBlucher_PipeFitting_Increaser_Eccentric_Type850 : 850.110.050
Socket Type_850.110.050Blucher_PipeFitting_Increaser_Eccentric_Type850 : 850.110.050
Socket Type_850.110.075Blucher_PipeFitting_Increaser_Eccentric_Type850 : 850.110.075
Socket Type_850.160.110Blucher_PipeFitting_Increaser_Eccentric_Type850 : 850.160.110
Spare Partsn/a
Type CommentsHub drains with round top 160 and 250 mm / 6 and 10”
Type NameHub drains with round top 160 and 250 mm / 6 and 10”
URLwww.blucher.com/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsmail@blucher.com
Waste ConnectionYes
X576 mm
