Gradus handrails, Dual Rails and combination rail are designed to offer pedestrian guidance and support in addition to a level of surface protection.

Designed for use in interior, horizontal circulation areas, they are suitable for use in a wide range of environments including education, healthcare, commercial office and transport.

  • Traditional handrail design available in a range of materials and finishes including PVC-u, aluminium, timber and stainless steel.

  • Offers a comfortable, smooth, continuous grip.

  • Meets the guidance for dimensions in relation to grip diameter, distance from the wall and bracket clearance.

  • Primarily designed to offer pedestrian support with a small element of wall protection.

This download is for the Gradus Handrails systems and contains the following types;

  • SHR40
  • THR450
